• ISO Solenoid Valve
ISO1 5/3 Way
Product Serial: BE394022 (CLOSED) / BE090022 (middle row)
Fluid : Filtered Air Lubricated or Lubricated Air
Connector (Connections) : (2)(4) =1/4"   (1)(3)(5) =3/8"
Traffic : 1200 NI/min (6bar)
Working pressure : 2~10bar
Ambient temperature range : -10~60°C
Body material : Aluminum
Seal Material : HNBR
Explosion levels (including connectors) : IP65
Weight (excluding connectors) : 0.462kg
